In contemporary electronic apparatuses, flexible circuit boards (FPC) are being utilized increasingly widely, particularly in the domain of high-performance and high-density packaging. To fulfill the requirements of these high-performance applications, the integration of multi-layer high density interconnect (HDI) technology and novel materials is crucial. This article will elaborate on the application of multi-layer HDI technology and its new materials, explore how they can significantly enhance the electrical performance and reliability of FPC, and spotlight the particulars that product development engineers need to pay attention to during the design and manufacturing process.

I. Overview of Multi-layer HDI Technology

1. What is Multi-layer HDI Technology?
High Density Interconnect (HDI) technology is an advanced printed circuit board (PCB) manufacturing technique that enables high-density line arrangement through the utilization of micro-holes, fine lines, and thin dielectric layers. Multi-layer HDI technology is based on this, where multiple HDI layers are stacked together to form a multi-layered structure to meet the demands of more complex and higher-density circuit designs.

2. Characteristics of Multi-layer HDI Technology
• High-density layout: Through micro-hole and fine-line technologies, multi-layer HDI can achieve a higher line density to meet the requirements of complex circuit designs.
Thinness: Multi-layer HDI employs thin dielectric layers to make the overall board thickness thinner, suiting for lightweight and thin electronic devices.
• High reliability: The utilization of micro-holes and fine lines reduces the signal transmission path, minimizes signal loss and delay, and enhances the reliability of the circuit.

II. The Application of Novel Materials

1. High-frequency and High-speed Materials
To meet the demands of high-frequency and high-speed signal transmission, new high-frequency and high-speed materials are extensively utilized in multi-layer HDI FPC. These materials possess the characteristics of low dielectric constant and low dielectric loss, which can effectively reduce the loss and delay during signal transmission.
• Examples: Polytetrafluoroethylene (PTFE) substrates, hydrocarbon substrates, etc.
2. High Heat-resistant Materials
In high-power applications, the FPC needs to withstand higher temperatures. The application of high heat-resistant materials can guarantee that FPC can maintain stable performance in high-temperature environments.
• Examples: Polyimide (PI) substrates, liquid crystal polymer (LCP) substrates, etc.
3. High Toughness Materials
To enhance the flexibility and folding resistance of FPC, the utilization of high toughness materials is particularly significant. These materials are capable of maintaining good electrical properties after multiple bendings.
• Examples: Modified polyimide (MPI) substrate, thermoplastic polyurethane (TPU) substrate, etc.

III. Enhancement of Electrical Performance and Reliability

1. Electrical Performance Enhancement
Low-loss transmission: The application of high-frequency high-speed materials significantly reduces signal transmission losses and improves signal integrity.
• Reduction of crosstalk: Multi-layer HDI technology reduces signal crosstalk by optimizing line layout and interlayer isolation.
Impedance control: Precise control of line width and dielectric layer thickness ensures impedance stability and improves signal transmission quality.
2. Reliability Enhancement
• High-temperature resistance: The application of high heat-resistant materials enables FPC to operate stably in high-temperature environments, prolonging the service life.
• Folding resistance: The utilization of high toughness materials improves the folding resistance of FPC, making it suitable for multiple bending applications.
• Chemical corrosion resistance: The new material has good chemical stability and can resist the corrosion of various chemicals, improving the environmental adaptability of FPC.

IV. The Focus of Product Development Engineers

1. Material Selection
• Select the appropriate substrate in accordance with the application requirements: for high-frequency and high-speed applications, select materials with low dielectric constant and low dielectric loss; for high-temperature environments, choose high heat-resistant materials; for multiple bending applications, select high toughness materials.
• Consider the processing properties of materials: choose materials that are easy to process and have good stability to ensure production efficiency and product quality.
2. Design Optimization
• Line layout optimization: rationalize the line layout, minimize the signal transmission path, reduce crosstalk and loss.
• Interlayer isolation design: Through rational interlayer isolation design, enhance signal integrity and anti-interference ability.
• Impedance matching design: accurately control the line width and dielectric layer thickness to ensure impedance matching and improve signal transmission quality.
3. Manufacturing Process Control
• Micro-hole machining accuracy: Ensure the machining accuracy of micro-holes, avoid rough hole walls and aperture deviations, which may affect electrical performance.
• Line accuracy control: Employ high-precision line processing technology to ensure the accuracy of line width and spacing.
• Laminating process optimization: Optimize the laminating process to ensure a strong bond between layers and avoid delamination and bubbles.

Conclusion
The integration of multi-layer HDI technology and novel materials provides robust support for the enhancement of electrical performance and reliability of FPC. As product development engineers, we need to profoundly understand the characteristics of these technologies and materials, make rational selection and application, and optimize the design and manufacturing process to ensure that the final product can meet the requirements of high-performance applications.

In the future, with the continuous enhancement of the performance of electronic devices, the application of multi-layer HDI technology and novel materials will be more extensive. Let us collaborate, constantly explore and innovate, and contribute to the development of the electronics manufacturing industry!
